Inel surub tip tata APS8 grad 80 M48x68
1.165,43 lei TVA Inclus (979,35 lei fara TVA )
Stoc epuizat
Anunta-ma cand revine in stoc
Inel ridicare cu surub APS8 grad 80
Dimensiune: M48x68
Capacitate de ridicare WLL : 32 tone
Greutate proprie aprox. 6.20 Kg
| Greutate | 6,2 kg |
|---|---|
| Dimensiuni | M48 |
| Tip produs | Inele |
Date tehnice
| APS8 | Marime | Dimensions (mm) | Greutate | |||||
|---|---|---|---|---|---|---|---|---|
| Stock No. | DxL | A | B | C | E | F | H | Kg |
| C80306 | M6x13 | 25 | 45 | 25 | 10 | 10 | 45 | 0.09 |
| C80308 | M8x13 | 25 | 45 | 25 | 10 | 10 | 45 | 0.09 |
| C80310 | M10x17 | 25 | 45 | 25 | 10 | 10 | 45 | 0.11 |
| C80312 | M12x21 | 35 | 63 | 35 | 14 | 14 | 62 | 0.27 |
| C80314 | M14x21 | 35 | 63 | 35 | 14 | 14 | 62 | 0.29 |
| C80316 | M16x27 | 35 | 63 | 35 | 14 | 14 | 62 | 0.31 |
| C80318 | M18x27 | 50 | 90 | 50 | 20 | 20 | 90 | 0.84 |
| C80320 | M20x30 | 50 | 90 | 50 | 20 | 20 | 90 | 0.86 |
| C80322 | M22x36 | 50 | 90 | 50 | 20 | 20 | 90 | 0.90 |
| C80324 | M24x36 | 50 | 90 | 50 | 20 | 20 | 90 | 0.90 |
| C80327 | M27x45 | 60 | 108 | 65 | 24 | 24 | 109 | 1.66 |
| C80330 | M30x45 | 60 | 108 | 65 | 24 | 24 | 109 | 1.70 |
| C80333 | M33x54 | 70 | 126 | 75 | 26 | 28 | 128 | 2.00 |
| C80336 | M36x54 | 70 | 126 | 75 | 26 | 28 | 128 | 2.15 |
| C80342 | M42x63 | 80 | 144 | 85 | 30 | 32 | 147 | 4.15 |
| C80348 | M48x68 | 90 | 166 | 100 | 35 | 38 | 168 | 6.20 |
| C80356 | M56x76 | 100 | 184 | 110 | 38 | 42 | 187 | 8.80 |
| C80364 | M64x90 | 110 | 206 | 120 | 42 | 48 | 208 | 12.40 |
| Size | WLL | Max. tightening couple |
|||||
|---|---|---|---|---|---|---|---|
 1 0° |  2 0° |  2 0-45° |  2 45-60° |  3-4 0-45° |  3-4 45-60° | Nm | |
| M6 | 0.40 | 0.8 | 0.14 | 0.10 | 0.20 | 0.14 | 3.50 |
| M8 | 0.80 | 1.6 | 0.28 | 0.20 | 0.40 | 0.28 | 8.00 |
| M10 | 1.00 | 2.00 | 0.35 | 0.25 | 0.50 | 0.35 | 16.00 |
| M12 | 1.60 | 3.20 | 0.56 | 0.40 | 0.80 | 0.56 | 28.00 |
| M14 | 3.00 | 6.00 | 1.00 | 0.75 | 1.50 | 1.00 | 45.00 |
| M16 | 4.00 | 8.00 | 1.40 | 1.00 | 2.00 | 1.40 | 70.00 |
| M18 | 5.00 | 10.00 | 1.80 | 1.25 | 2.50 | 1.80 | 95.00 |
| M20 | 6.00 | 12.00 | 2.10 | 1.50 | 3.00 | 2.10 | 135.00 |
| M22 | 7.00 | 14.00 | 2.40 | 1.75 | 3.5 | 2.4 | 182.00 |
| M24 | 8.00 | 16.00 | 2.80 | 2.00 | 4.00 | 2.80 | 182.00 |
| M27 | 10.00 | 20.00 | 3.50 | 2.50 | 5.00 | 3.50 | 343.00 |
| M30 | 12.00 | 24.00 | 4.20 | 3.00 | 6.00 | 4.20 | 465.00 |
| M33 | 14 | 28.00 | 4.80 | 3.40 | 6.80 | 4.80 | 632.00 |
| M36 | 16.00 | 32.00 | 5.60 | 3.90 | 7.80 | 5.40 | 814.00 |
| M42 | 24.00 | 48.00 | 8.40 | 5.90 | 11.80 | 8.20 | 1304.00 |
| M48 | 32.00 | 64.00 | 12.2 | 7.80 | 15.60 | 10.90 | 1981.00 |
| M56 | 36.00 | 72.00 | 12.6 | 8.80 | 17.60 | 12.30 | 3000.00 |
| M64 | 45.00 | 90.00 | 15.7 | 11.10 | 22.00 | 15.40 | 4736.00 |
