Chinga urechi MC 150 5 tone 5 metri
664,02 lei TVA Inclus (558,00 lei fara TVA )
13 în stoc
Chinga textile de ridicat sarcini model MC 150
Capacitate de ridicare WLL 5 tone
Culoare: Rosu – Cod de culori in concordanta cu EN 1492-1
Latime banda 150 mm
Lungime chinga ridicare: 5 metri
Grosime banda 7 mm
Chinga textila fabricata in 2 straturi
Factor de siguranta 7:1
Modalitate de livrare: 1 bucata
Productie: Tara de origine Olanda
- Material chinga Poliester / Protectie pentru ureche / culoare albastra , din material rezistent
- Eticheta de idendificare produs din material rezistent , marcaj CE
- Produsele sunt certificate VGS, GS sau LLOYD
- Eticheta albastra = material poliester / Eticheta de identificare laterala / pentru lungime chinga
- Domeniul de lucru de la -40 grade C pana la + 100 grade C
- In conformitate cu directiva masini 2006/42 EC In conformitate cu EN 1492-1
- Cod de culori in concordanta cu EN 1492-1
| Greutate | 4,39 kg |
|---|---|
| Capacitate | 5 tone |
| Lungime | 5 metri |
| Tip produs | Chingi ridicare urechi |
Date tehnice
| Color | Type | W.L.L. | Webbing width in mm | Thickness in mm | Eye length 1m effective length in mm (L2) | Eye length 2m effective length in mm(L2) | Eye length 3m effective length in mm(L2) | Standard eye type | Weight 1 meter in Kg (L1) | Weight 2 meter in Kg (L1) | Weight 2 meter in Kg (L1) | Weight each meter extra |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | MC30 | WLL 1t | 30 | 7 | 250 | 400 | type 1 | 0.25 | 0.45 | 0.65 | 0.2 | |
 | MC60 | WLL 2t | 60 | 6 | 250 | 400 | type 3 | 0.44 | 0.79 | 1.14 | 0.35 | |
 | MC90 | WLL 3t | 90 | 7.5 | 250 | 400 | type 3 | 0.71 | 1.25 | 1.8 | 0.55 | |
 | MC120 | WLL 4t | 120 | 8 | 450 | type 4 | 1.67 | 2.4 | 0.73 | |||
 | MC150 | WLL 5t | 150 | 7 | 550 | type 4 | 2.12 | 3.06 | 0.94 | |||
 | MC180 | WLL 6t | 180 | 7 | 600 | type 4 | 2.95 | 4.14 | 1.2 | |||
 | MC240 | WLL 8t | 240 | 8 | 750 | type 4 | 5.25 | 1.5 | ||||
 | MC300 | WLL 10t | 300 | 7 | 1000 | type 4 | 6.85 | 1.97 | ||||
| MC300 | WLL 12t | 300 | 8 | 1000 | type 4 | 8.35 | 2.36 |
| Conform EN 1492-1/2 | Capacitate de incarcare pentru o chinga cu urechi sau circulara | ||||||
|---|---|---|---|---|---|---|---|
| Drept | Lat | *β | *β | *β | |||
| 0°-7° | 7°-45° | 45°-60° | 7°-45° | 45°-60° | |||
 |  |  |  | |  | |
|
| Factor | 1 | 0.8 | 2 | 1.4 | 1 | 0.7 | 0.5 |
| WLL in tone | |||||||
| 1 | 0.8 | 2 | 1.4 | 1 | 0.7 | 0.5 |
| 2 | 1.6 | 4 | 2.8 | 2 | 1.4 | 1 |
| 3 | 2.4 | 6 | 4.2 | 3 | 2.1 | 1.5 |
| 4 | 3.2 | 8 | 5.6 | 4 | 2.8 | 2 |
| 5 | 4 | 10 | 7 | 5 | 3.5 | 2.5 |
| 6 | 4.8 | 12 | 8.4 | 6 | 4.2 | 3 |
| 8 | 6.4 | 16 | 11 | 8 | 5.6 | 4 |
| 10 | 8 | 20 | 14 | 10 | 7 | 5 |
| 12 | 9.6 | 24 | 16.8 | 12 | 8.4 | 6 |
| 15 | 12 | 30 | 21 | 15 | 10.5 | 7.5 |
| 20 | 16 | 40 | 28 | 20 | 14 | 10 |
| 25 | 20 | 50 | 35 | 25 | 17.5 | 12.5 |
| 30 | 24 | 60 | 42 | 30 | 21 | 15 |
| 40 | 32 | 80 | 56 | 40 | 28 | 20 |
| 50 | 40 | 100 | 70 | 50 | 35 | 25 |
| 60 | 48 | 120 | 84 | 60 | 42 | 30 |
| 70 | 56 | 140 | 98 | 70 | 49 | 35 |
| 80 | 64 | 160 | 112 | 80 | 56 | 40 |
| 90 | 72 | 180 | 126 | 90 | 63 | 45 |
| 100 | 80 | 200 | 140 | 100 | 70 | 50 |
| 110 | 88 | 220 | 154 | 110 | 77 | 55 |
| 115 | 92 | 230 | 161 | 115 | 80.5 | 57.5 |
| Conform EN 1492-1/2 | Capacitate de incarcare pentru doua chingi cu urechi / circulara | ||||
|---|---|---|---|---|---|
| *β | *β | ||||
| 7°-45° | 45°-60° | 7°-45° | 45°-60° | ||
|  | |  | |
|
| Factor | 1.4 | 1 | 0.7 | 0.5 | |
| WLL in tone | |||||
| 1 | 1.4 | 1 | 1.12 | 0.8 |
| 2 | 2.8 | 2 | 2.24 | 1.6 |
| 3 | 4.2 | 3 | 3.36 | 2.4 |
| 4 | 5.6 | 4 | 4.48 | 3.2 |
| 5 | 7 | 5 | 5.6 | 4 |
| 6 | 8.4 | 6 | 6.72 | 4.8 |
| 8 | 11.2 | 8 | 8.96 | 6.4 |
| 10 | 14 | 10 | 11.2 | 8 |
| 12 | 16.8 | 12 | 13.44 | 9.6 |
| 15 | 21 | 15 | 16.8 | 12 |
| 20 | 28 | 20 | 22.4 | 16 |
| 25 | 35 | 25 | 28 | 20 |
| 30 | 42 | 30 | 33.6 | 24 |
| 40 | 56 | 40 | 44.8 | 32 |
| 50 | 70 | 50 | 56 | 40 |
| 60 | 84 | 60 | 67.2 | 48 |
| 70 | 98 | 70 | 78.4 | 56 |
| 80 | 112 | 80 | 89.6 | 64 |
| 90 | 126 | 90 | 100.8 | 72 |
| 100 | 140 | 100 | 112 | 80 |
| 110 | 154 | 110 | 123.2 | 88 |
| 115 | 161 | 115 | 128.8 | 92 |
