Chinga urechi MC 240 8 tone 8 metri

Name: Chinga urechi MC 240 8 tone 8 metri
SKU: MC24008
Availability: InStock

1.848,98 lei TVA Inclus (1.528,08 lei fara TVA )

6 în stoc

❤ Adauga in wishlist!

SKU: MC24008 Categorii: CHINGI RIDICARE & ACCESORII, CHINGI URECHI Etichete: chinga ridicare, chinga textila urechi, chinga urechi, chingi ridicare, chingi textile, chingi textile urechi, chingi urechi stoc Bucuresti, sufa textila, sufa urechi stoc Bucuresti, sufe macarale

Chinga textile de ridicat sarcini model MC 240
Capacitate de ridicare WLL 8 tone
Culoare: Albastru – Cod de culori in concordanta cu EN 1492-1
Latime banda 240 mm
Lungime chinga ridicare: 8 metri
Grosime banda 8 mm
Chinga textila fabricata in 2 straturi
Factor de siguranta 7:1
Modalitate de livrare: 1 bucata
Productie: Tara de origine Olanda

Material chinga Poliester / Protectie pentru ureche / culoare albastra , din material rezistent
Eticheta de idendificare produs din material rezistent , marcaj CE
Produsele sunt certificate VGS, GS sau LLOYD
Eticheta albastra = material poliester / Eticheta de identificare laterala / pentru lungime chinga
Domeniul de lucru de la -40 grade C pana la + 100 grade C
In conformitate cu directiva masini 2006/42 EC In conformitate cu EN 1492-1
Cod de culori in concordanta cu EN 1492-1

Greutate	13,91 kg
Capacitate	8 tone
Lungime	8 metri
Tip produs	Chingi ridicare urechi

Date tehnice

Type	W.L.L.	Webbing width in mm	Thickness in mm	Eye length 1m effective length in mm (L2)	Eye length 2m effective length in mm(L2)	Eye length 3m effective length in mm(L2)	Standard eye type	Weight 1 meter in Kg (L1)	Weight 2 meter in Kg (L1)	Weight 2 meter in Kg (L1)	Weight each meter extra
MC30	WLL 1t	30	7	250	400		type 1	0.25	0.45	0.65	0.2
MC60	WLL 2t	60	6	250	400		type 3	0.44	0.79	1.14	0.35
MC90	WLL 3t	90	7.5	250	400		type 3	0.71	1.25	1.8	0.55
MC120	WLL 4t	120	8		450		type 4		1.67	2.4	0.73
MC150	WLL 5t	150	7		550		type 4		2.12	3.06	0.94
MC180	WLL 6t	180	7		600		type 4		2.95	4.14	1.2
MC240	WLL 8t	240	8			750	type 4			5.25	1.5
MC300	WLL 10t	300	7			1000	type 4			6.85	1.97
MC300	WLL 12t	300	8			1000	type 4			8.35	2.36

Conform EN 1492-1/2	Capacitate de incarcare pentru o chinga cu urechi sau circulara
	Drept	Lat	*β	*β		*β
	Drept	Lat	0°-7°	7°-45°	45°-60°	7°-45°	45°-60°

Factor	1	0.8	2	1.4	1	0.7	0.5
WLL in tone
	1	0.8	2	1.4	1	0.7	0.5
	2	1.6	4	2.8	2	1.4	1
	3	2.4	6	4.2	3	2.1	1.5
	4	3.2	8	5.6	4	2.8	2
	5	4	10	7	5	3.5	2.5
	6	4.8	12	8.4	6	4.2	3
	8	6.4	16	11	8	5.6	4
	10	8	20	14	10	7	5
	12	9.6	24	16.8	12	8.4	6
	15	12	30	21	15	10.5	7.5
	20	16	40	28	20	14	10
	25	20	50	35	25	17.5	12.5
	30	24	60	42	30	21	15
	40	32	80	56	40	28	20
	50	40	100	70	50	35	25
	60	48	120	84	60	42	30
	70	56	140	98	70	49	35
	80	64	160	112	80	56	40
	90	72	180	126	90	63	45
	100	80	200	140	100	70	50
	110	88	220	154	110	77	55
	115	92	230	161	115	80.5	57.5

Conform EN 1492-1/2		Capacitate de incarcare pentru doua chingi cu urechi / circulara
		*β		*β
		7°-45°	45°-60°	7°-45°	45°-60°

Factor		1.4	1	0.7	0.5
WLL in tone
	1	1.4	1	1.12	0.8
	2	2.8	2	2.24	1.6
	3	4.2	3	3.36	2.4
	4	5.6	4	4.48	3.2
	5	7	5	5.6	4
	6	8.4	6	6.72	4.8
	8	11.2	8	8.96	6.4
	10	14	10	11.2	8
	12	16.8	12	13.44	9.6
	15	21	15	16.8	12
	20	28	20	22.4	16
	25	35	25	28	20
	30	42	30	33.6	24
	40	56	40	44.8	32
	50	70	50	56	40
	60	84	60	67.2	48
	70	98	70	78.4	56
	80	112	80	89.6	64
	90	126	90	100.8	72
	100	140	100	112	80
	110	154	110	123.2	88
	115	161	115	128.8	92
