Inel pulita tip mama APM8 M30 grad 80
352,24 lei TVA Inclus (296,00 lei fara TVA )
Stoc epuizat
Anunta-ma cand revine in stoc
Ochet cu piulita APM 8 grad 80 tip mama
Marime: M30
Capacitate: 12 tone
Diametru interior: A= 60 mm
Inaltime totala: H = 109 mm
Greutate proprie aprox.: 1.40 kg
| Greutate | 1,4 kg |
|---|---|
| Dimensiuni | M30 |
| Tip produs | Inele |
Date tehnice
| APM8 | Marime | Dimensions (mm) | Greutate | |||||
|---|---|---|---|---|---|---|---|---|
| Stock No. | DxL | A | B | C | E | F | H | Kg |
| C80206 | M6 | 25 | 45 | 25 | 10 | 10 | 45 | 0.10 |
| C80208 | M8 | 25 | 45 | 25 | 10 | 10 | 45 | 0.10 |
| C80210 | M10 | 25 | 45 | 25 | 10 | 10 | 45 | 0.10 |
| C80212 | M12 | 35 | 63 | 35 | 14 | 14 | 62 | 0.26 |
| C80214 | M14 | 35 | 63 | 35 | 14 | 14 | 62 | 0.26 |
| C80216 | M16 | 35 | 63 | 35 | 14 | 14 | 62 | 0.26 |
| C80218 | M18 | 50 | 90 | 50 | 20 | 20 | 90 | 0.75 |
| C80220 | M20 | 50 | 90 | 50 | 20 | 20 | 90 | 0.75 |
| C80224 | M24 | 50 | 90 | 50 | 20 | 20 | 90 | 0.75 |
| C80227 | M27 | 60 | 108 | 65 | 24 | 24 | 109 | 1.40 |
| C80230 | M30 | 60 | 108 | 65 | 24 | 24 | 109 | 1.40 |
| Dimensiune | WLL | Max. tightening couple |
|||||
|---|---|---|---|---|---|---|---|
 1 0° |  2 0° |  2 0-45° |  2 45-60° |  3-4 0-45° |  3-4 45-60° | Nm | |
| M6 | 0.40 | 0.8 | 0.14 | 0.10 | 0.20 | 0.14 | 3.50 |
| M8 | 0.80 | 1.6 | 0.28 | 0.20 | 0.40 | 0.28 | 8.00 |
| M10 | 1.00 | 2.00 | 0.35 | 0.25 | 0.50 | 0.35 | 16.00 |
| M12 | 1.60 | 3.20 | 0.56 | 0.40 | 0.80 | 0.56 | 28.00 |
| M14 | 3.00 | 6.00 | 1.00 | 0.75 | 1.50 | 1.00 | 45.00 |
| M16 | 4.00 | 8.00 | 1.40 | 1.00 | 2.00 | 1.40 | 70.00 |
| M18 | 5.00 | 10.00 | 1.80 | 1.25 | 2.50 | 1.80 | 95.00 |
| M20 | 6.00 | 12.00 | 2.10 | 1.50 | 3.00 | 2.10 | 135.00 |
| M24 | 8.00 | 16.00 | 2.80 | 2.00 | 4.00 | 2.80 | 182.00 |
| M27 | 10.00 | 20.00 | 3.50 | 2.50 | 5.00 | 3.50 | 343.00 |
| M30 | 12.00 | 24.00 | 4.20 | 3.00 | 6.00 | 4.20 | 465.00 |
| M36 | 16.00 | 32.00 | 5.60 | 3.90 | 7.80 | 5.40 | 814.00 |
| M42 | 24.00 | 48.00 | 8.40 | 5.90 | 11.80 | 8.20 | 1304.00 |
| M48 | 32.00 | 64.00 | 11.2 | 7.80 | 15.60 | 10.90 | 1981.00 |
| M56 | 36.00 | 72.00 | 12.6 | 8.80 | 17.60 | 12.30 | 3000.00 |
| M64 | 45.00 | 90.00 | 15.7 | 11.10 | 22.00 | 15.40 | 4736.00 |
