Inel surub rotativ APWB M12x18 0.5 tone
373,66 lei TVA Inclus (314,00 lei fara TVA )
10 în stoc
Inel ridicare flexibil cu surub rotativ APWB grad 80
Dimensiune: M12x18
Capacitate de ridicare WLL : 0.5 tone
Greutate proprie aprox. 0.50 Kg
| Greutate | 0,5 kg |
|---|---|
| Capacitate | 0.5 tone |
| Dimensiuni | M12 |
| Tip produs | Inele |
Date tehnice
| APWB | Marime | WLL | Dimensions (mm) | Greutate | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Stock No. | mm | tone | A | B | C | E | H | SW | D1 | Kg |
| C8000030816 | M8x16 | 0.3 | 30 | 13 | 46 | 50 | 105 | 30 | 38 | 0.48 |
| C8000031018 | M10x18 | 0.3 | 30 | 13 | 46 | 50 | 105 | 30 | 38 | 0.48 |
| C8000051218 | M12x18 | 0.5 | 30 | 13 | 46 | 50 | 105 | 30 | 38 | 0.5 |
| C8000051225 | M12x25 | 0.5 | 30 | 13 | 46 | 50 | 105 | 30 | 38 | 0.5 |
| C8000101620 | M16x20 | 1.12 | 30 | 13 | 46 | 50 | 105 | 30 | 38 | 0.53 |
| C8000101630 | M16x30 | 1.12 | 30 | 13 | 46 | 50 | 105 | 30 | 38 | 0.53 |
| C8000102030 | M20x30 | 1.12 | 30 | 13 | 46 | 50 | 105 | 30 | 38 | 0.53 |
| C8000202030 | M20x30 | 2 | 34 | 16 | 57 | 61 | 131 | 40 | 50 | 1.05 |
| C8000302430 | M24x30 | 3.15 | 40 | 19 | 70 | 68 | 153 | 48 | 58 | 1.63 |
| C8000503035 | M30x35 | 5.3 | 40 | 20 | 65 | 80 | 165 | 65 | 75 | 2.23 |
| C8000503045 | M30x45 | 5.3 | 40 | 20 | 65 | 80 | 165 | 65 | 75 | 2.23 |
| C8000803035 | M30x35 | 8 | 50 | 22 | 90 | 95 | 205 | 75 | 85 | 5.3 |
| C8000803045 | M30x45 | 8 | 50 | 22 | 90 | 95 | 205 | 75 | 85 | 5.3 |
| C8000803654 | M36x54 | 8 | 50 | 22 | 90 | 95 | 205 | 75 | 85 | 5.5 |
| C8001004263 | M42x63 | 10 | 50 | 22 | 90 | 95 | 205 | 75 | 85 | 10 |
| C8001504860 | M48x60 | 15 | 70 | 30 | 120 | 130 | 280 | 95 | 120 | 10 |
| C8001505678 | M56x78 | 15 | 70 | 30 | 120 | 130 | 280 | 95 | 120 | 10 |
| C8001506496 | M64x96 | 15 | 70 | 30 | 120 | 130 | 280 | 95 | 120 | 10 |
| C80025072108 | M72x108 | 25 | 68 | 40 | 127 | 165 | 338 | 134 | 170 | 29 |
| C80030080120 | M80x120 | 30 | 68 | 40 | 127 | 165 | 338 | 134 | 170 | 29 |
| C80035090135 | M90x135 | 35 | 68 | 40 | 127 | 165 | 338 | 134 | 170 | 29 |
| Working Load Limit | WLL | Max. tightening couple |
|||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| To. |  1 0° |  2 0° |  1 90° |  2 90° |  2 0-45° |  2 45-60° |  2 unsymm. |  3-4 0-45° |  3-4 45-60° |  3-4 unsymm. | Nm |
| 0.3 | 0.6 | 1.2 | 0.3 | 0.6 | 0.42 | 0.3 | 0.3 | 0.63 | 0.45 | 0.3 | 16 |
| 0.5 | 1 | 2 | 0.5 | 1 | 0.75 | 0.5 | 0.5 | 1.1 | 0.75 | 0.5 | 28 |
| 1.12 | 2 | 4 | 1.12 | 2 | 1.5 | 1.12 | 1.12 | 2.36 | 1.6 | 1.12 | 70 |
| 2 | 4 | 8 | 2 | 4 | 2.8 | 2 | 2 | 4 | 3 | 2 | 135 |
| 3.15 | 6.3 | 12.5 | 3.15 | 6.3 | 4.25 | 3.15 | 3.15 | 6.3 | 4.75 | 3.15 | 230 |
| 5.3 | 10.6 | 21.2 | 5.3 | 10.6 | 7.1 | 5.3 | 5.3 | 11.2 | 8 | 5.3 | 465 |
| 8 | 12.5 | 25 | 8 | 16 | 11.2 | 8 | 8 | 16.8 | 12 | 8 | 465 |
| 10 | 15 | 30 | 10 | 20 | 14 | 10 | 10 | 21.2 | 15 | 10 | 1304 |
| 15 | 25 | 50 | 15 | 30 | 21 | 15 | 15 | 31.5 | 22.5 | 15 | 1981 |
| 25 | 35 | 70 | 25 | 50 | 35 | 25 | 25 | 52.5 | 37.5 | 25 | 6913 |
| 30 | 35 | 70 | 30 | 50 | 42 | 30 | 30 | 63 | 45 | 30 | 9625 |
| 35 | 35 | 70 | 35 | 70 | 49 | 35 | 35 | 73.5 | 52.5 | 35 | 14000 |
