Inel surub rotativ LBO-L M36 8 tone

Name: Inel surub rotativ LBO-L M36 8 tone
SKU: 8-211-080L
Price: 2486.00 RON
Availability: InStock

2.958,34 lei TVA Inclus (2.486,00 lei fara TVA )

1 în stoc

❤ Adauga in wishlist!

SKU: 8-211-080L Categorii: INELE FLEXIBILE ROTATIVE GRAD 100, INELE RIDICARE & ANCORARE Etichete: inel flexibil LBO-L tija lunga, inel surub rotativ stoc Bucuresti, inele ridicare flexibile grad 100, livrare rapida, surub rotativ flexibil tija lunga

Inel surub flexibil rotativ LBO-L grad 100
Capacitate ridicare: 8000 kg
Dimensiune filet: M36
Lungime filet maxima : 222 mm
Greutate proprie aprox. 7.10 Kg

Greutate	7,1 kg
Capacitate	8 tone
Dimensiuni	M36
Tip produs	Inele

Date tehnice

LBO	Working Load Limit	Thread	Dimensions (mm)										Torque in Nm	Weight Each	Screw extension E in mm
Stock No.	To.	M	A	B	C	D	E	F	G	H	S	SW	Nm	Kg	Standard	max. Lange
8-211-003L	0.30	M8	30	35	35	10	76	85	55	29	6	13	30	0.2	11	76
8-211-006L	0.63	M10	30	35	36	10	96	85	55	29	6	17	60	0.4	16	96
8-211-010L	1.00	M12	33	37	44	14	114	98	57	36	8	19	100	0.5	18	114
8-211-015L	1.50	M16	33	37	46	14	149	98	57	36	10	24	150	0.7	24	149
8-211-025L	2.50	M20	50	54	57	17	186	140	82	44	12	30	250	1.7	30	186
8-211-040L	4.00	M24	50	54	59	17	221	140	82	44	14	36	400	2.0	36	221
8-211-050L	5.00	M30	60	65	81	23	278	170	99	62	17	46	500	4.4	48	278
8-211-080L	8.00	M36	77	85	101	27	222	225	124	78	22	55	800	7.1	62	222
8-211-100L	10.00	M42	77	85	104	27	272	225	124	78	24	65	1000	8.5	72	272
8-211-150L	15.00	M42	95	104	112	36	264	256	158	86	24	65	1500	13.0	57	264
8-211-200L	20.00	M48	95	104	120	36	295	259	158	90	27	75	2000	14.7	72	295
