Inel surub rotativ LBO M42 10 tone

Name: Inel surub rotativ LBO M42 10 tone
SKU: 8-211-100
Availability: InStock

2.630,54 lei TVA Inclus (2.174,00 lei fara TVA )

3 în stoc

Inel surub flexibil rotativ LBO grad 100
Capacitate ridicare: 10000 kg
Dimensiune filet: M42
Greutate proprie aprox. 6.3 Kg

Date tehnice

LBO	Working Load Limit	Thread	Dimensions (mm)										Torque in Nm	Weight Each
Stock No.	To.	M	A	B	C	D	E	F	G	H	S	SW	Nm	Kg
8-211-003	0.30	M8	30	35	35	10	11	85	55	29	6	13	30	0.2
8-211-006	0.63	M10	30	35	36	10	16	85	55	29	6	17	60	0.3
8-211-010	1.00	M12	33	37	44	14	18	98	57	36	8	19	100	0.5
8-211-012	1.20	M14	33	37	45	14	21	98	57	36	10	22	120	0.5
8-211-015	1.50	M16	33	37	46	14	24	98	57	36	10	24	150	0.5
8-211-020	2.00	M18	50	54	57	17	26	140	82	44	12	30	200	1.3
8-211-025	2.50	M20	50	54	57	17	30	140	82	44	12	30	250	1.3
8-211-040	4.00	M24	50	54	59	17	36	140	82	44	14	36	400	1.4
8-211-042	4.00	M27	60	65	79	23	38	170	99	62	17	41	400	2.8
8-211-050	5.00	M30	60	65	81	23	48	170	99	62	17	46	500	3.1
8-211-070	7.00	M36	60	65	88	23	54	178	99	65	22	55	700	3.3
8-211-080	8.00	M36	77	85	101	27	62	225	124	78	22	55	800	5.8
8-211-100	10.00	M42	77	85	104	27	72	225	124	78	24	65	1000	6.3
8-211-150	15.00	M42	95	104	112	36	63	256	158	86	24	65	1500	10.8
8-211-200	20.00	M48	95	104	120	36	72	259	158	90	27	75	2000	11.6

LBO	Working Load Limit	Thread	WLL
Stock No.	To.	M	1 0°	2 0°	1 90°	2 90°	2 0-45°	2 45-60°	2 unsymm.	3-4 0-45°	3-4 45-60°	3-4 unsymm.
8-211-003	0.30	M8	0.30	0.60	0.30	0.60	0.42	0.30	0.30	0.63	0.45	0.30
8-211-006	0.63	M10	0.63	1.26	0.63	1.26	0.88	0.63	0.63	1.32	0.95	0.63
8-211-010	1.00	M12	1.00	2.00	1.00	2.00	1.40	1.00	1.00	2.10	1.50	1.00
8-211-012	1.20	M14	1.20	2.40	1.20	2.40	1.70	1.20	1.20	2.50	1.80	1.20
8-211-015	1.50	M16	1.50	3.00	1.50	3.00	2.10	1.50	1.50	3.10	2.20	1.50
8-211-020	2.00	M18	2.00	4.00	2.00	4.00	2.80	2.00	2.00	4.20	3.00	2.00
8-211-025	2.50	M20	2.50	5.00	2.50	5.00	3.50	2.50	2.50	5.20	3.70	2.50
8-211-040	4.00	M24	4.00	8.00	4.00	8.00	5.60	4.00	4.00	8.40	6.00	4.00
8-211-042	4.00	M27	4.00	8.00	4.00	8.00	5.60	4.00	4.00	8.40	6.00	4.00
8-211-050	5.00	M30	5.00	10.00	5.00	10.00	7.00	5.00	5.00	10.50	7.50	5.00
8-211-070	7.00	M36	7.00	14.00	7.00	14.00	9.80	7.00	7.00	17.70	10.50	7.00
8-211-080	8.00	M36	8.00	16.00	8.00	16.00	11.20	8.00	8.00	16.80	12.00	8.00
8-211-100	10.00	M42	10.00	20.00	10.00	20.00	14.00	10.00	10.00	21.00	15.00	10.00
8-211-150	15.00	M42	15.00	30.00	15.00	30.00	21.00	15.00	15.00	31.50	22.50	15.00
8-211-200	20.00	M48	20.00	40.00	20.00	40.00	28.00	20.00	20.00	42.00	30.00	20.00
