Ochet surub DIN580 M22

Name: Ochet surub DIN580 M22
SKU: A173Z22
Price: 32.35 RON
Availability: InStock

~~38,50 lei~~ 34,65 lei TVA Inclus (29,12 lei fara TVA )

1118 în stoc

Inel ridicare surub tip tata DIN 580
Marime: M22
Capacitate SWL: 1.5 tone
Lungime tija: 30 mm
Greutate proprie aprox.: 0.48 kg

Date tehnice

Marime	Dimensiuni ( mm )								S.W.L.	45 S.W.L.	90 S.W.L.	Max Tightening couple	Weight
	A	B	C	E	F	G	H	L	Kg	Kg	Kg	Nm	Kg
M6	20	36	20	6	8	10	36	13	90	60	45	3.5	0.060
M8	20	36	20	6	8	10	36	13	140	100	70	8	0.060
M10	25	45	25	8	10	12	45	17	230	170	115	16	0.110
M12	30	54	30	10	12	14	53	20.5	340	240	170	28	0.170
M14	30	54	30	10	12	14	53	20.5	500	350	250	45	0.170
M16	35	63	35	12	14	16	62	27	700	500	350	70	0.310
M20	40	72	40	14	16	19	71	30	1200	860	600	135	0.480
M22	40	72	40	14	16	19	71	30	1500	1050	750	182	0.480
M24	50	90	50	18	20	24	90	36	1800	1290	900	230	0.900
M27	54	98	62	20	22	26	99	40	2500	1830	1250	343	1.250
M30	60	108	65	22	24	28	109	45	3200	2300	1600	465	1.700
M33	60	108	65	22	24	28	109	45	4200	3050	2100	632	1.900
M36	70	126	75	26	28	32	128	54	4600	3300	2300	814	2.150
M39	80	144	85	30	32	38	147	63	6000	4400	3000	1059	4.000
M42	80	144	85	30	32	38	147	63	6300	4500	3150	1304	4.150
M45	90	166	100	35	38	46	168	68	7800	5500	3900	1638	6.100
M48	90	166	100	35	38	46	168	68	8600	6100	4300	1981	6.200
M52	100	184	110	38	42	50	187	78	9900	7100	4950	2540	8.600
M56	100	184	110	38	42	50	187	78	11500	8200	5750	3000	8.800
M64	110	206	120	42	48	58	208	90	16000	11000	8000	4736	12.400
M72	140	260	150	50	60	72	260	100	20000	14000	10000	6913	22.500
M80	160	296	170	55	68	80	298	112	28000	20000	14000	9625	34.500
M100	180	330	190	60	75	88	330	130	40000	29000	20000	19613	47.800
